ENGLISH
Explanation of general view
1 Protrusion of loop handle
2 Matching hole in gear housing
3 Shaft lock
4 Loop handle
5 Bolts
6 Hex wrench
7 Wool pad
8 Sleeve 18
9 Backing pad
10 Spindle
11 Press
12 Switch trigger
13 Lock button
14 Speed adjusting dial
15 Lock nut
16 Abrasive disc
17 Rubber pad
18 Lock nut wrench
19 Loosen
20 Tighten
21 Limit mark
22 Screwdriver
23 Brush holder cap
SPECIFICATIONS
Model 9227CB
Max. capacities (dia.)
Wool pad ................................................... 180 mm
Abrasive disc ............................................. 180 mm
No load speed (min -1 ) ................................ 0 – 3,000
Overall length ............................................... 470 mm
Net weight ....................................................... 3.0 kg
• Due to our continuing program of research and
development, the specifications herein are subject
to change without notice.
• Note: Specifications may differ from country to
country.
Power supply
The tool should be connected only to a power supply
of the same voltage as indicated on the nameplate,
and can only be operated on single-phase AC supply.
They are double-insulated in accordance with Euro-
pean Standard and can, therefore, also be used from
sockets without earth wire.
Safety hints
For your own safety, please refer to the enclosed
safety instructions.
ADDITIONAL SAFETY RULES
ENB047-3
1. Always use eye and ear protection. Other
personal protective equipment such as dust
mask, gloves, helmet and apron should be
worn when necessary. If in doubt, wear the
protective equipment.
2. Always be sure that the tool is switched off
and unplugged before carrying out any work
on the tool.
3. Accessories must be rated for at least the
speed recommended on the tool warning
label. Wheels and other accessories running
over rated speed can fly apart and cause
injury.
4. Check the backing pad carefully for cracks,
damage or deformity before operation.
Replace cracked, damaged or deformed pad
immediately.
5. Check that the workpiece is properly sup-
ported.
6. Hold the tool firmly.
7. Keep hands away from rotating parts.
8. Make sure abrasive disc or wool bonnet is not
contacting the workpiece before the switch is
turned on.
9. When sanding metal surfaces, watch out for
flying sparks. Hold the tool so that sparks fly
away from you and other persons or flam-
mable materials.
10. Do not leave the tool running. Operate the tool
only when hand-held.
11. Pay attention that the wheel continues to
rotate after the tool is switched off.
12. Do not touch the workpiece immediately after
operation; it may be extremely hot and could
burn your skin.
13. If working place is extremely hot and humid, or
badly polluted by conductive dust, use a
short-circuit breaker (30 mA) to assure opera-
tor safety.
14. Do not use the tool on any materials contain-
ing asbestos.
15. Do not use water or grinding lubricant.
16. Ventilate your work area adequately when you
perform sanding operations.
17. Always use the correct dust mask/respirator
for the material and application you are work-
ing with.
18. Ensure that ventilation openings are kept clear
when working in dusty conditions. If it should
become necessary to clear dust, first discon-
nect the tool from the main supply (use non
metallic objects) and avoid damaging internal
parts.
SAVE THESE INSTRUCTIONS.
