twice before pressing the SETUP Push-button.

2. Use the Down directional Push-button on the Re-

mote Control to select the PROGRESSIVE MODE

Menu. Refer to figure 34.

3. To change from the default setting use the Right

directional Push-button followed by Up or Down

directional Push-buttons and then press the SELECT

Push-button.

Note: The title of the icon button-bar will change color

from yellow (the cursor color) to blue indicating

the selected item.

4. Return to the Video Setup Menu by pressing the Left

followed by the Up directional Push-buttons.

5. Next continue to the PIXEL CROPPING Settings. If

no other changes are to be made in Setup Mode at this

time, exit by pressing the RTRN (Return) Push-button.

Note: The SETUP Push-button may also be pressed to

exit the setup mode.

Pixel Cropping

A small number of TV/Monitors might exhibit some

horizontal instability (jitter). This can be removed by Pixel

Cropping Circuitry in the MVP871. To activate perform

the following:

1. Press the SETUP Push-button on the supplied Remote

Control to access the Language Setup Menu. Then

press the Right directional Push-button to select the

Video Menu Icon Tab. Refer to figure 24.

Note: If there

is a Disc

playing

in the

MVP871

press

the

STOP

Push-

button

twice

before

pressing

the SETUP Push-button.

2. Use the Down directional Push-button on the Re-

mote Control to select the PIXEL CROPPING Menu.

Refer to figure 35.

3. To change from the default setting use the Right

directional Push-button followed by Up or Down

directional Push-buttons and then press the SELECT

Push-button.

Note: The title of the icon button-bar will change color

from yellow (the cursor color) to blue indicating

the selected item.

Note: The title

of the

icon

button-

bar will

change

color

from

yellow

(the

cursor

color)

to blue

indicating the selected item.

4. Return to the Video Setup Menu by pressing the Left

followed by the Up directional Push-buttons.

5. Next continue to the PROGRESSIVE MODE Settings.

If no other changes are to be made in Setup Mode at

this time, exit by pressing the RTRN (Return) Push-

button.

Note: The SETUP Push-button may also be pressed to

exit the setup mode.

Progressive Mode

When the Component Video Output (Analog Video) is

connected to the TV/Monitor and the Progessive Mode is

set to Auto (default setting) the MVP871 will produce the

best possible picture quality. The two additional Modes of

Progressive Scan “Video1” and “Video2” allow for manual

override when the Progressive Scan Circuits can not

detemine whether the video signal is film or video based.

Video1 setting will look best with Video Source material

and Video2 will look best with Film Source material. For

additional important information on using the Component

Video Outputs and the Progressive Scan Mode refer to

“Component Video” on page 27. To switch Off the Proges-

sive Scan Mode perform the following:
