page 14 —MQp240 generaTor • operaTion and parTs Manual — rev. #0 (10/23/12)

instaLLatiOn

GROUN

D

GROUND ROD
FOR EARTH
GROUND

GROUND CABLE

GENERATOR
GROUND LUG

CONNECT TO
BUILDING
GROUND

8 FT. MINIMUM

REFERENCE
NEC 250-52(C)

Figure 2. Typical Generator Grounding Application
