page 12 —MQp240 generaTor • operaTion and parTs Manual — rev. #0 (10/23/12)
sPEcificatiOns
Table 1. generator specifications
Model MQP240
Type
Revolving field, self ventilated,
open protected type synchronous generator
armature Connection star with neutral
phase 3
standby output 260 KW
prime output 240 KW
3Ø voltage (l-l/l-n)
voltage Change-over Bd. at 3Ø 240/139
208Y/120, 220Y/127, 240Y/139
3Ø voltage (l-l/l-n)
voltage Change-over Bd. at 3Ø 480/277
416Y/240, 440Y/254, 480Y/277
power Factor 0.8
Frequency 60 Hz
speed 1800 rpm
aux. aC power Single Phase, 60 Hz
aux. voltage/output 4.8 Kw (2.4 kW x 2)
dry Weight 8,811 lbs. (4,000 kg)
Wet Weight 9,010lbs. (4,091 kg)
Table 2. engine specifications
Model Cummins QSL9-G3 Tier 3
Type
4 cycle, water-cooled, direct injection, turbo-charged
with air to air after-cooler
no. of Cylinders 6 cylinders
Bore x stroke 4.49 in. x 5.69 in. (114 mm x 145 mm)
displacement 543 cu. in. (8900 cc)
rated output 363 HP at 1800 rpm
starting Electric
Coolant Capacity 11.3 gal. (43.0 liters)
lube oil Capacity 7.0 gal. (26.5 liters)
Fuel Type #2 Diesel Fuel
Fuel Consumption
19.0 gal. (72.0 L)/hr at full load 15.5 gal. (58.6 L)/hr at 3/4 load
11.1 gal. (41.9 L)/hr at 1/2 load 5.9 gal. (22.4 L)/hr at 1/4 load
Battery 150 Ah x 2 (24V System)
