Section 3

Ice Machine Operation

Part Number 80-1631-3

3-1

Section 3

Ice Machine Operation

Component Identification

sv3150

sv3149

Check Valve

Ice Thickness Probe

Dump Valve

Toggle Switch

Water Curtain

Water Distribution Tube

Water Level Probe

Water Pump

Water Inlet Location

Water Inlet Valve

(Located in Refrigeration Compartment)

Bin Switch

Curtain Retainer
