DCa25Usi 60 hz generaTor • operaTion anD parTs manUal — rev. #3 (07/19/11) — page 51
generatOr assy.
no. parT no. parT name QTY. remarKs
1 B1110200602 ROTOR ASSY 1
1-1 FIELD ASSY 1
1-2 7961025004 RECTIFIER 1
1-3 0601822630 SURGE ABSORBER 1
1-4 8001070003 FAN 1
1-5 8351611004 COUPLING DISK 2
1-6 8351612004 WASHER, COUPLING HUB 1
1-7 B1112300003 BALANCING PLATE .................................1 ....... PURCHASE ITEM 1- 10 AS A SET
1-8 0010310025 HEX HEAD BOLT 4
1-9 0042510000 WASHER, LOCK 4
1-10 0601000209 BALANCING WEIGHT KIT 1
1-11 0071906308 BEARING 1
2 0010308035 HEX HEAD BOLT 6
2A 0040008000 WASHER, LOCK 6
2B 0041208000 WASHER, FLAT 6
3 0070506803 BEARING 1
4 B1130201103 STATOR ASSY 1
4-1 0845041904 GROMMET 1
5 B1138000003 FIELD ASSY, EXCITER 1
6 0016008045 HEX SOCKET HD CAP SCREW 1
7 0042508000 WASHER, LOCK 3
8 8351315003 END BRACKET 1
9 0017108035 HEX HEAD BOLT 6
10 8351312004 PACKING 1
11 8351331004 COVER, SUCTION 1
12 0017106016 HEX HEAD BOLT 3
13 0010310030 HEX HEAD BOLT 6
13A 0040010000 WASHER, LOCK 6
13B 0041210000 WASHER, FLAT 6
14 B0155400204 COVER, FAN 1
15 0010106030 HEX HEAD BOLT 1
16 0041206000 WASHER, FLAT 1
17 0600815000 NUT 1
18 M9312600004 RUBBER SUSPENSION 2
19 0207010000 HEX NUT 2
