Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
10 30A** Front wipers
11 30A** PCM/Power sustain
12 40A** Blower motor
13 10A* A/C clutch
14 10A* Heater/Coolant pump
15
50A** Traction Battery Control Module
(TBCM)
16 40A** Cooling fan 1
17 40A** Cooling fan 2
18 50A** ABS solenoid
19 30A** Power seats
20 — A/C clutch relay
21A — Rear defroster relay
21B — Not used
21C — Blower relay
21D — PCM relay
22 — Not used
23 5A* TBCM
24 20A* Fuel pump
25 15A* Ignition coils
26 5A* TBCM
27 10A* Cooling fan/TCM
28 15A* Heated Exhaust Gas Oxygen
(HEGO) sensor
29 15A* PCM power
30A — Cooling fan 1 relay
30B — Power sustain relay
30C — Cooling fan main relay
30D — Cooling fan 2 relay
31A — Reverse lamp relay
31B — Injector relay
