Features and Specs at a Glance
Encodes HF Chips •
Prints Bar Code Data •
Prints Tags or Labels •
Thermal Direct or •
Transfer
Knife Option •
Prints up to 12 ips •
Optional 300 dpi Printing •
Dual Wired/Wireless •
Ethernet Available
Dimensions: Height – 13.0” (330 mm); Width
– 12.5” (318 mm); Depth – 17.3” (439 mm)
Weight – 29 lbs. (13.2 kg)
Printing Method: Thermal Direct and Thermal
Transfer
Printhead: 4.0” (102 mm/812 dots); 203 dots/inch
(8 dots/mm) OR 300 dots/inch (11.8 dots/mm.
Both printheads provide enhanced print quality
Operator Interface: 32-Bit 150 MHz Processor
RFID Protocols: ISO 15693-2,-3; ISO 18000-3; TI
Tag-It 15693; NXP I-Code; TagSys C270, C370
Memory: 4MB Flash, 16 MB SDRAM Optional
16MB; Configurable 8 MB RAM using these
buffers: Transmit, Receive, Image, Format,
Downloadable & Scalable Fonts
Bar Code Types: UPCA +2/+5, UPCE +2/+5,
EAN8 +2/+5, EAN13 +2/+5, Interleaved 2
of 5, Extended Code 39, Codabar (NW7),
Code 128, Code 93, MSI, PDF417, Postnet,
MaxiCode, Code 16K, Quick Response (QR
Code); Aztec
Standard Fonts: Bitmap- Standard, Reduced,
Bold, OCRA-like, CG Triumvirate, and CG
Triumvirate Bold TrueType
® - EFF Swiss Bold
Supports downloaded double-byte (TrueType
and bitmap) fonts, allowing for Chinese,
Japanese, and Korean character sets
Font Magnification: 1x to 7x 4 to 250 pt. for
scalable/TrueType fonts
Monarch ® Service: Every Monarch printer is fully
supported by Monarch Service, the largest network
of experienced, full-time bar code and RFID
technicians in the industry.
Monarch ® 9855 ® HF TM
High Frequency RFID Printer/Encoder
Versatile RFID
The Monarch 9855HF printer/
encoder supports a range of HF
protocols including ISO 15693-2,
-3, TI Tag-IT, NXP I-Code and
ISO-18000-3 and is compatible
with a full range of inlays to
complement your specific
application, including inlays from:
• Rafsec
• TAGSYS
• TI
• More!
Monarch ® Supplies: For smooth and reliable
performance, only Monarch supplies are
recommended for use with Monarch printers.
Our labels scan virtually 100% of the time,
cutting wasted rescanning and labeling time.
We won’t approve an inlay
until it meets Avery Dennison’s
exacting yield standards!
Compliant RFID
The Monarch 9855HF printer
meets OSHA requirements
for use in a workplace and is
FCC certified, RoHS compliant
and certified for use in over 40
countries. In addition, Avery
Dennison’s printer and supply
manufacturing processes are
ISO-9001 certified.
Connected RFID
Our innovative Dual Wireless
802.11b/g/Wired Ethernet
network interface card option
allows you to run your printers
on a wireless network, with
the ability to change to a wired
connection. Automatically switch
from wireless to the wired ethernet
port while retaining the IP address
and without losing the session,
enhancing your productivity.
XML-enabled printers are currently
unavailable.
