3.
Optional Fiber Modules
This section introduces the optional 100FX modules, which can be installed
on the front panel of the MIL-S1600 switch. Each optional 100FX Module
supports a one-port fiber connector.
The 100FX Modules are designed to extend the distance between the MIL-
S1600 and other devices. The maximum distance connected by optical fiber is
up to 2 Km multi-mode fiber or 15 to 60 Km with single-mode fiber.
Figure 3-1. The optional 100FX Module
There are five 5 types of fiber port connectors available including SC, ST, MT-
RJ, VF-45 connectors.
