OM-4428 Page 17
4-4. Volt-Ampere Curves For CC/CV Models
217 811 / 203 415 / 217 810
The volt-ampere curves show the
minimum and maximum voltage
and amperage output capabilities of
the welding generator. Curves of all
other settings fall between the
curves shown.
A. Stick Mode
B. MIG Mode
C. TIG Mode
0
20
40
60
80
100
0 100 200 300 400 500 600 700 800 900
DC AMPERES
DC VOL
TS
Ranges
275−Max
150−525
110−390
80−240
50−125
0
20
40
60
80
100
0 100 200 300 400 500 600 700 800 900 1000
DC AMPERES
DC VOL
TS MAX
MIN
0
20
40
60
80
100
0 100 200 300 400 500
DC AMPERES
DC VOL
TS
1000
Ranges
50−440
35−320
25−215
15−115
