Motion 42-02-S028 User Manual
User guide, universal serial network
Table of contents
Document Outline
- Motion Control Engineering, Inc. 11380 White Rock Road Rancho Cordova, CA 95742 voice 916 463 9200 fax 916 463 9201 www.mceinc.com
- User Guide, Universal Serial Network
- Important Precautions and Useful Information
- Safety and Other Symbol Meanings
- In This Manual
- USN Installation
- IMC, PTC, PHC Installation
- Mounting the Board Assemblies
- 1. Determine an appropriate location for the USN-BASE assembly. (Preferred location is in the upper left quadrant of the control enclosure.)
- 2. Mount the board, facing outward, such that access to critical controller components is not blocked.
- 3. For PTC/PHC programmable controllers, mount the M2C assembly near the USN-BASE assembly. (For a duplex, mount an M2C assembly in each controller enclosure but just one USN-BASE assembly in the enclosure of your choice.)
- 1. Determine an appropriate location for the USN-BASE assembly. (Preferred location is in the upper left quadrant of the control enclosure.)
- Mounting the Board Assemblies
- Motion 3000ES Installation
- USN Power Connection, Elevators
- Power Connection, Escalators
- IMC, PTC, PHC Installation
- Configuration
- Device Type
- 1. Set only the F7 switch UP.
- 2. Press N until Device Type is displayed.
- 3. Press S to select. Supported Device Types are:
- 4. Select the Device Type.
- 5. Press N to go to save menu. Press S to save.
- 6. After the device type has changed, place the F7 switch down.
- 7. Reset the USN board by pressing the RSTA button.
- 8. After the device reboots, confirm new device type is selected.
- 1. Set only the F7 switch UP.
- Escalator Only
- IP Setup
- Device Type
- Communication Connections
- IMC
- 1. Connect the external Ethernet cable to Ethernet Port A on the USN-BASE assembly.
- 2. Connect the supplied C-RJ11/DB9M cable from a controller MC-RS (serial board) COM port to RS232 Port B (J7) on the USN-BASE assembly.
- 3. Through the controller MPU board, set the connected COM port to media= serial and device= PC.
- 4. On the MC-RS board, set the connected COM port slide switch to DCE.
- 5. Press RSTA to reset the USN board so that it will read its new connections.
- 1. Connect to the group controller using a CRT, terminal emulator, or TigerTerm software.
- 2. Press F1, then 1 to get to the General configuration screen.
- 3. Access the ICOM setting. Set it to the COM port connected to the MC-USN board. For example, if the MC- USN board is connected to COM2 on the MC-RS board, set the ICOM setting to COM2.
- 4. Save.
- 5. With the Function Switch F8 switch UP (all others down), press N to cycle through the menu to verify that information is correct.
- 1. Connect the external Ethernet cable to Ethernet Port A on the USN-BASE assembly.
- PTC/PHC
- 1. Connect the external Ethernet cable to Ethernet Port A on the USN-BASE assembly.
- 2. The boards in the controller are connected along a ribbon cable bus. Connect the M2C assembly’s “From PCA” (JP3) to the last controller board on the bus using supplied ribbon cable.
- 3. Connect the M2C assembly’s CAN2 port to the “Internal Network” (J5) connector on the USN-BASE assembly using the C-RJ-11 cable .
- 4. For Duplex, connect both CAN2 ports on the M2C assembly to supplied splitter. Then plug the splitter into “Internal Network” (J5) connector on USN-BASE assembly.
- 5. Press RSTA to reset the USN board so that it will read its new connections.
- 6. With the Function Switch F8 switch UP (all others down), press N to cycle through the menu to verify that information is correct.
- 1. Connect the external Ethernet cable to Ethernet Port A on the USN-BASE assembly.
- Motion 3000ES
- IMC
- MC USN Information
- Security Password Default for IMC Connections
- KCE Functionality
