Configuration
5
Escalator Only
If you are not configuring an escalator, proceed to IP Setup.
An escalator connection has additional parameters that need to be configured. Please note:
each escalator must have its own unique lift number.
1. Place switch F7 in the up position. Using the keypad as described earlier, set and save:
• Job Name: Defines the job name displayed on the iMonitor Summary screen.
• Job Number: Defines the job number displayed on iMonitor Summary screen.
• Number of Escalators: Defines the number of escalators the USN will be monitoring on
the CAN bus.
• If only one escalator is to be connected to the USN, choose the 1 (AUTO) setting. This
setting assumes that only one escalator will be connected to the USN board and it will
automatically detect the lift number on the bus.
• If more than one escalator is on the bus the USN will connect to the first one it sees.
Since detection is automatic the Escalator Connection menu is not shown.
• Escalator Connection: The USN has the ability to group up to 4 escalators in a group. This
parameter maps the lift number that will be the first escalator in the group, second escala-
tor, and so on.
• Escalator Label: This two-character value will be displayed in iMonitor under the escalator
grouping. For example, you could set lift 2 to display as “E2”.
2. Proceed to IP Setup.
IP Setup
You may need to consult an IT person to find out the appropriate IP settings for your network.
With the F7 switch in the up position, set:
• IP Address
• Subnet Mask
• Gateway Address
• Other options (MCE use only)
Important
• After defining network settings, you must reset the USN board by disconnect-
ing and reconnecting the IDC power connector.
