Appendix A
Technical Reference
Product Specifications
Bus interface 32-bit PCI
Number of ports 2
I/O address Assigned by PCI BIOS
IRQ Assigned by PCI BIOS
Data bits 5, 6, 7, 8
Stop bits 1, 1.5, 2
Parity none, even, odd, space, mark
UART Moxa UART (16C550C or compatible)
Speed 50 bps to 921.6 Kbps
Connector CP-102U: Female DB25
CP-102UL: Male DB9
Data signals RS-232 TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Surge protection 15 KV ESD
Operating temperature 0 to 55°C
Power requirement 93 mA max. (+5V, RS-232)
Dimensions CP-102U: 120 × 80 mm (4.72 × 3.15 in)
CP-102UL: 120 × 64.5 mm (4.72 × 2.54 in)
