1 Introduction
CommPlete Communications Server 3
Technical Specifications
Input voltage 100 VAC to 240 VAC RMS
Input frequency 50/60 Hz
Input current 8 A @ 115 V at full load
4 A @ 230 V at full load
Output voltage at
maximum current 5 VDC @ 65 A
21 VDC @ 0.5 A
5 V regulation ± 0.1% at full load
5 V OVP 125-132% of output voltage
Dielectric strength,
input to output 3750 VRMS per EN60950
Indicator LED for power good indication
Environmental Temperature range: 0°–40° C (32°–104° F)
Humidity range: 0–95% (noncondensing)
Dimensions 7.3 cm × 17.1 cm × 29.8 cm (H × W × D)
2.88 in.× 6.75 in.× 11.75 in. (H × W × D)
Weight 2.27 kg (5 lb)
Limited Warranty Two years
Fuses 12 A 250 V fast blow
Manual Organization
Chapter 1 Introduction
This chapter describes the PS9600, gives its technical specifications, and provides a guide to the
organization of the manual.
Chapter 2 Installation
This chapter describes how to install the PS9600 into the CommPlete chassis
Chapter 3 Operation
This chapter describes briefly how to operate the PS9600 power supply.
Chapter 4 Solving Problems
This chapter describes how to troubleshoot the PS9600 and adjust the output.
