Electrical connection
Electrical connections should be
made by a qualified electrician in
accordance with local and national
codes and ordinances.
Note to the installer:
Please leave these instructions with
the consumer.
Power supply
The oven is equipped with a 4 wire
cord ready for connection to a dedi-
cated 120/240 V, 60 Hz, single phase,
3 pole - 4 wire grounding power supply.
Caution:
Disconnect the oven from the main
power supply before servicing. To
reduce the risk of electric shock,
make sure that the appliance is
properly grounded after installation.
Black wire: connect to L1 (hot)
Red wire:
connect to L2 (hot)
White wire: connect to N (neutral)
Green wire: connect to GND (ground)
A dedicated line and junction box
should be used to connect the oven to
a 20 A circuit.
Connection details are given on the
diagram located on the top of the oven.
