Repair Parts List
99
2
Grip,
Handle,
Yellow
19074
100
2
Spring, Dampener, Retract
26963
101
2
Bolt, 5/16-18 x 1 1/4" Low Socket Hd., Cap, Bk.
26327
102
2
Bumper, 1"x 5/8" Long
33603
103
2
Screw, 1/2-20 x 1 1/2" Set Lock, Black
18663
104
2
Block, Guide-Platform Stow
28593
105 2 Pin,
Platform
975-2325
106
10
Screw, 5/16-18 x 3/4", SHFS
25527
107
2
Spacer, UHMW, Vertical Channel
995-0320
108
2
Nut, 1/4-20 Nylock
14614
109
2
Bracket, Mounting, Quiet Ride
915-0392
110
2
Gas Spring, 12.2" Extended/8.3" Compressed
30550A
111
2
Bolt, 5/16-18 x 3/4", Carriage, Black
15858BK
112
3
Washer, 5/16", External Tooth
16368
113
4
Nut, 5/16-18 Hex
10058
114
2
Bracket, Inner Side Panel Guide
915-0703
115
3
Bearing, UHMW, Flat, Thin, Black
916-5406
116
2
Pivot, Bridge Plate Lever, Upper, Inside
916-5433
117
4
Bearing, Flange - 3/4" x 1/2"
24027
118
1
Spacer, UHMW, Latch
950-7760
119
1
Spring, 1/4" x 1" Extension w/Hooks
10774
120
1
Tubing, Polyurethane - 1/4" I.D. x 1/2" O.D. x .81"
28630R000.81
121
2
Pin, Clevis, 3/8" x 3", Black
24932BK
122
1
Pin, Platform Cylinder
915-0414
123
2
Ring, Snap, 1/2", External, .035" Thick
20946
124
1
Weldment,
Tube-IB
Fold
Arm-Rear
985-0625RNW
125
1
Lever, Roll Stop Latch (Assembly #915-0345A)
915-0435
126
4
Nut, 3/8-16, Hex
10059BK
127
1
Weldment,Tube-IB
Fold
Arm-Front
985-0625FNW
128
1
Pivot, Roll Stop Cylinder, Front
990-0352
129
2
Bolt, 5/16-18 x 1 1/2" Hex Head, Cap
10014
130
2
Bolt, 7/16-20 x 1", SHCS, w/Nylock Patch
28474
131
4
Screw, #10-32 x 3/8", Flat Head, Hex
24537
132
3
Adapter, Cylinder/Roll Stop Lever-Out
990-0341
133
4
Nut, #10-32, w/Lockwasher
18349
134
6
Rivet, Pop, 3/16"-.25"/.38", Black
14993
135
1
Adapter, Cylinder/Roll Stop Lever
915-0341N
136
2
Harness, Sensor - Cherry w/Plug
30433A60
137
4
Rivet, Snap, Black, .158/.197 Thick
25759
138
4
Clamp, Cable, 1/2", Plastic
10092
139
2
Nut, 5/16-18, Top Lock, Black
28324BK
140
2
Bolt, 1/4-20 x 1/2", Button Head Socket
15733
141
2
Bolt, 3/8-16 x 2", Hex Head, Cap
10027
142
2
Roller
Assembly
1000-2395A
143
2
Roller
Retainer
915-5353
144
2
Nut, 5/16-18 Hex, Lock
11387BK
145
2
Pivot, Bridge Plate Lever, Upper-Outer
916-5434
146
6
Clamp, 1/4" I.D.- Nylon Loop
84396
147
2
Clip, Hand Control Hanger
84389
148
12
Rivet, Snap, .201" x .256"/.295"
26362
149
4
Bearing, Flange, 1" x 1/2-16FDU08
28031
150
1
Cover, Plastic, Parallel Arm, O/S Rear-w/Tape
915-0702NA
151
1
Weldment, Bridgeplate Bracket, Front
985-0431FNW
152
4
Spacer, Handrail, .375” Thk. UHMW
995-0301
153
2
Washer, .516" I.D. x .75" O.D. x .250", Black
25336
154
1
Cover, Plastic, Parallel Arm, I/S Rear-w/Tape
975-0703NA
155
1
Weldment, Bridgeplate Bracket, Rear
985-0431RNW
156
2
Spring, Torsion - .366 I.D. x .05"
30386
157
4
Spacer, IB Lock
30394
158
2
Weldment, IB Lock
985-0630NW
159
4
Bearing, 3/8" I.D. x 1/2" Long
30405
160
4
Roller, .65" O.D. x 1/2" Long
985-0631N
161
4
E-Clip, 3/8" Shaft
84383
162
2
Spacer, Handrail, .230" Thk. UHMW
911-5301
163
1
Magnet - Sensor Ring
30662
164
1
Harness, Sensor - Magnetic w/Plug
31030A45
165
1
Rivet, Snap, Black, .201" Hole x .177"/.217" Thick 30408
166
2
Bearing, Flange, 3/8" x 1/4" - Plastic
24028
167
2
Light Assy, Vertical Channel
31062A
168
1
Tab, Outer Barrier - Assembly
915-6367NA
169
1
Washer, .4" I.D. x .810" O.D. x .12"
24536
170
4
Spacer, UHMW-.75" O.D. x .39" I.D. x .25"
30227
171
1
Bolt, 3/8-16 x 3/4" Soc. Hd. Cap Screw Bk.
26259
172
1
Spacer, Flap Cylinder .700" Thick
915-0415
173
1
Guard, Rollstop Sensor Wires
915-0368N50Y
174
1
Parallel Arm Assy., Bottom w/Bearings-Front
985-0457NA
175
4
Screw, #10-32 x 1/2" Button Head, Socket, Cap
30375
176
1
Bearing Assy., UHMW Flat w/Magnet
205-1760NA
177
1
Slide, UHMW,Platform Rotate, Magnet
31009
178
3
Rivet, Pop, 3/16" - .13/.25" - SD64BS
11513
179
2
Harness,
Sensor-Reed
31254A
180
4
Screw, #4-40 x 1/4" Phillips Pan Head, Thread Cut
31043
181
1
Screw, 10-32 x 5/8" Pan Head Phillips, Thd. Cut
26714
182
1
Adapter, Cylinder/Roll Stop Lever
915-0344
183
1
Rivet, Snap, Black, .201" Hole x .217"/.256" Thick
25973
184
2
Bolt, 1/4-20 x 1", Hex
10001
185
2
Nut, 1/4-20, Hex
10057
186
2
Washer, 1/4" External Tooth
83588
Item Qty.
Description
Part
No.
Item Qty.
Description
Part
No.
Part Numbers of Items Identical on All Lift Models
Item Qty.
Description
NL917IB
Part Numbers of Items Dedicated per Lift Model
1 1 Base
Weldment
985R1148KS33
2
1
Cover, Pump, 2-Piece, Back-Bottom
915-0513RNA
3
1
Cover, Pump, 2-Piece, Top-Front Assy.
915-0519RNA
4
1
Platform
Weldment
917-03350NW
5
1
Outer Barrier Assembly (inc. 5,13,31,168,181)
915-0312NA33Y
6
1
Inner Roll Stop
915-0147NWY
7
1
Bridge Switch Assembly
31010RA
8
1
Block, Platform Stop - Bridging - Rear
25778
9
1
Block, Platform Stop - Bridging - Front
900-0311
10
1
Plate, Backing/Mounting Rear
985-0501RN
11
1
Bag, Vinyl - 7" x 10"
31174
12
3
Washer, #10, Flat, Auto BK
11541
13
2
Rivet, Pop, 3/16" x .06"/.13"
11512
14
8
Washer, .516" I.D. x 1" O.D. x .0269", Auto BK
15328
15
4
Washer, Finger, Disc Spring
27276
16
4
Snap-Ring
1/2"
13273
17
4
Snap-Ring
5/16"
24570
18
4
O-Ring, 5/16" I.D. x 1/16" O.D.
26614
19
2
Screw, Socket Head, 3/8-16 x 1/2" with 1/2" Shoulder
25929
20
1
Grommet, I.D. .281"/ FR.125" x GD.625"/T.375"
27725
21
1
Pivot, Roll Stop Lever
24550
22
11
Rivet, Pop, 1/8"- .13"/.19"
12954
23
1
Stud, Wing Head
28804
24
1
Retainer,
Push-On
28805
25
1
Grommet, ID .312", FR .250", GD .813" T500"
27726
26
1
Pump
Assembly
31038-12V
27
10
Pin, Pivot, Parallel Arm
917-0403
28
10
Screw Drive #8 x 3/16" Long Black 31086BK
29
1
Receptacle,
Clip-On
28803
30
1
Cylinder Assembly, Roll Stop (inc. Fittings & Items 30 & 123)
25309-05AK
31
1
Rubber Nose, 33"
24603-33
32
1
Latch Assembly, Roll Stop
915-4343NA
33
2
Bolt, 5/16-18 x 1/2" Nylock, Hex
10012
34
2
Washer, 5/16" Flat
10063
35
2
Bolt, 3/8-16 x 1/2" Nylock, Hex
29729
36
6
Bolt, 5/16-18 x 3/4", Button Head, Soc Cap Hd
24440
37
2
Microswitch
Assembly
975-3121A
38
2
Bolt, 5/16-18 x 3/4" Nylock, Hex
29608
39
1
Rivet, Pop, SD68 BSLF-3/16" - .38"/.50"
15244
40
1
Parallel
Arm
Assy.,
Top-Front
w/Bearings
915-0437FA
41
4
Bearing, Flange, 1/2" x 1/4"
24442
42
1
Weldment, Latch, Lift/Tite, Rear
27013RW
43
1
Weldment, Latch, Lift/Tite, Front
27013FW
44
2
Screw, #4-40 x 5/8", Round Head
14810
45
1
Clip, Cable, 5/16", Plastic
26948
46
1
Screw, #8-32 x 1", Mach. Truss Head
19912BK
47
2
Nut, #4-40 w/Lockwasher
19537
48
2
Nut, #8-32, Hex
10777
49
1
Parallel
Arm
Assy.,
Top-Rear
w/Bearings
975-2437RA
50
2
Cylinder, 14.625"/29.146" Retracted
C1514.3-9408
51
1
Parallel Arm Assy., Bottom w/Bearings and Sensors - Rear
985-1458NA
52
16
Bearing, Flange, 3/4" x 3/8"
24011
53
8
Bushing, 3/4" I.D. x 1/2"
900-0456
54
1
Vertical Channel Weldment, Front, 48"
955-0448FNW
55
1
Cover, Plastic, Parallel Arm, O/S Front-w/Tape
915-0704NA
56
2
Tape, 1" Wide S-Face Foam, x 14" (1 Shown)
82015R014
57
6
Tape, 1" Wide S-Face Foam, x 10" (3 Shown)
82015R010
58
1
Cycle Counter-LCD Without Reset
30547
59
2
Handrail
Weldment
985-0618NW
60
8
Rivet, Push In - 8MM
30063
61
4
Bumper, Rubber, 31/32" O.D.
10950
62
2
Screw, #8-18 x 1/2", Self-Tap, Phillips
13583
63
2
Bulb, Light 20-W, Halogen Reflector 31060
64
2
Bolt, Carriage, 1/4-20 x 3/4"
13434
65
1
Base, Cover -33"
975-0148CN33
66
2
Washer, 3/8" Flat, Black
10064
67
4
Nut, 3/8-16, Hex Lock
13617
68
2
Cotter Pin, 1/4" x 2", Black
15886BK
69
1
Cam Wmt, Microswitch, Opposite Pump Side
985-0834NW
70
1
Cover, Plastic, Parallel Arm, I/S Front-w/Tape
975-0701NA
71
2
Threshold Strip Switch
31221A
72
4
Screw, 1/4-20 x 1/2" FHSCS
18860
73
8
Washer, Finger Disk Spring
30772
74
10
Washer, 1/2" Flat Black Zinc
25346
75
2
Bolt, 3/8-16 x 1", Hex
10025
76
6
Washer, 3/8", Lock, Black
10069BK
77
2
Lever, Inboard Barrier
985-0404N
78
4
Clamp, Insulate, 1 3/8" I.D.
29765
79
2
Washer, 5/16" Lock, Black
10068
80
2
Gas Spring, Fold Arm
29186
81
2
Ball Stud, Gas Spring, 13MM x 3/8-16 F. Thread
29185
82
2
Washer, 3/8", Lock
10069
83
1
Spacer, Flap Cylinder .184" Thick
915-0416
84
2
Clip, Safety, 3/8-16 x 3/4", Flange
12608
85
6
Bolt, 3/8-16 X 3/4", Flange Button Head, Socket Cap
25171
86
2
Bolt, 5/16-18 x 2", Flange, Hex
25130
87
2
Nut, 5/16-18, Serrated Flange
25131
88
2
Arm, Slide Support
985-6612N
89
2
Slide, Platform, Rotate, Weldment
985-0606N
90
2
Spacer, .5" O.D. x .334" I.D. x 1.515" LG
25132
91
10
Bearing, Flange, 3/4" x 1/4"
24012
92
2
Weldment, Platform Pivot Arm - 48"
985-0640NW-BKN
93
2
Pin, Pivot, Lower Arm
900-0413N
94
6
Ring, Snap, 3/4", External
18657
95
2
Bearing, UHMW, Flat, 1.226"
205-1760
96
2
Ball Stud, 10MM
21301
97
1
Vertical Channel Weldment, Rear
955-0448RNW
98
6
Plastic End Cap, 1" I.D. x 1 1/4" O.D.
20474
