Pump Module
Parts List
* Apply red #271 Thread Locker Loctite
®
to the four hex bolts (items 36 and 37) if a blue nylon patch is not present on
the bolts when retrofitting an M268-0113 pump assembly. Loctite
®
is available from The Braun Corporation under part
number 11522.
t Indicates items available for replacement part purposes only. These items are not included with replacement pump
modules.
Item Qty.
Description
Part
No.
1
Pump Module (complete), 12 Volt, Rear
917-A1516RNA
1
1
Pump Assembly (M268-0113) 12V-120G - Dual Relief / ARS (Includes Items 2 & 3)
31038-12V
2
1
Power Cable, Up Solenoid to Motor
29049
3
1
Solenoid, Up - 4-Post - Trombetta
31129
4
1
Diode Assembly, Up Solenoid
73906A
5
4
Nut, #10-32, Serrated Flange
83080
6
2
Fitting, Male 7/16-20 O-Ring to Male 7/16-20 JIC 37°
24504
7
1
Elbow, Female Swivel 7/16-20 JIC 37° to (2) Male 7/16-20 JIC 37°
26579
8
1
Switch,
Pressure
31199
9
1
Control, Hand Pendant Assembly - Standard (Includes Items 10-18)
100063-001
10
1
Keypad, Hand Control
30000
11
1
Hand Pendant Case - Front
100027-001
12
1
Seal, Hand Control - Standard
100066-001
13
1
Module, Hand Control
100041-001
14
1
Screw, 10-32 x 1/2”, Phillip, Pan Head
82744
15
1
Hand Pendant Case - Rear
100028-001
16
1
Hanger, Round - Hand Control
73793
17
2
Screw, #4-40 x 1/4”, Phillip, Pan Head
11480
18
1
Cord, Coiled - 6-Conductor
100044-001
19
1
Shield,
Electrical
31304
20
1
Control
Board
Assembly
100080-001
21
1
Plate, Backing / Mounting - Rear
985-0501RN
22
8
Standoff,
Snap-In
31011
23
1
Cover, Pump, 2-Piece - Back (Complete Assembly 915-0513RNA Includes Items 23 - 30)
915-0513RN
24
1
Recepticle, Clip On
28803
25
1
Lens, Threshold Warning - Red
30704
26
1
Decal, Warning / Pressure Relief Valve (Not shown - see Decal Section)
22249
27
1
Spacer, Lens - NHTSA
31386
28
1
Metal Ring Base - Lamp
30971
29
1
Socket,
Lamp
30703
30
3
Screw, #8-32 x 1/2” Pan Head Phillips - Thread Cut
30974
31
1
Bulb, Light
19841
32
1
Diode, Green LED, Panel Mount
29545
33
1
Strain Relief - Liquid Tight
30753
34
1
Rivet, Snap, .201” x .217”/.256”
25973
35
2
Washer, 5/16” Flat
10063
36
2
Bolt, 5/16-18 x 3/4”, Nylock, Hex * See note below
29608
37
2
Bolt, 5/16-18 x 1/2”, Nylock, Hex * See note below
10012
38
1
Cable, Ground
26161A
39
1
Washer, 5/16” External Tooth
16368
40
1
Beeper,
Continuous
30487
41
1
Switch,
Toggle
12185
42
1
Decal, Lift Power - On/Off (Not shown - see Decal Section)
21494
43
1
Stud, Power Feed
26084
44
1
Rubber Boot, Red tSee note below
82046
45
1
Harness, Interlock Interface
31077A
46
1
Pump Handle with Grip
17206A
47
1
Cover, Pump - 2-Piece - Top / Front (Complete Assembly
915-0519RNA
Includes Items 47 - 59)
915-0519RN
48
3
Rivet, Pop, SD43BS - 1/8” - .13”/.19”
12954
49
1
Plug, Window - Clear
30443
50
1
Stud, Wing Head - 1/4 Turn
28804
51
1
Retainer, Push On
28805
52
1
Washer, Nylon, 1/4” I.D. x 11/16” O.D. x .030”
12690
53
1
Clip, Pump Handle - Top
915-5517
54
1
Clip, Pump Handle - Bottom
915-5518
55
1
Decal, Manual Instructions - Public (Not shown - see Decal Section)
31412
56
1
Decal, Removal / Installaton - Pump Cover (Not shown - see Decal Section)
29051
57
1
Decal, Warning - Control Board Damage - ESD (Not shown - see Decal Section)
30787
58
1
Decal, Removal / Installation Pump Handle (Not shown - see Decal Section)
29052
59
1
Decal, Installation & Warning - Hydraulic Pressure Switch (Not shown - see Decal Section)
27154
60
1
Clamp, Hose - Solenoid Mounting
29663
61
1
Ground Wire, Motor
31263A
62
1
Solenoid, 4-Post
28308MOD
