INST70-2054
7
OLDSMOBILE
- Aurora 2002-03 w/ RPO code U80
- Intrigue 2002 w/ RPO code U85
PONTIAC
- Grand Prix 2002-03 w/ RPO code U85
NOTE
These wire colors do not follow the EIA/Metra color code
A1-A4
Not Used
A5 Orange
Right Rear Speaker (+)
A6 Gray
Right Rear Speaker (-)
A7 Dark Blue/White Left Rear Speaker (+)
A8 Dark Blue
Left Rear Speaker (-)
A9 Brown/White
Right Front Speaker (+)
A10 Brown
Right Front Speaker (-)
A11 Blue
Left Front Speaker (+)
A12 Yellow
Left Front Speaker (-)
B1-B12
Not Used
A
Not Used
B White
Right Rear Sub (-)
C Violet
Left Rear Sub (-)
D-E
Not Used
F Dark Blue/Pink
Left Rear Sub (+)
G Brown/Yellow
Right Rear Sub (+)
H
Not Used
