84
Your mecablitz provides full lighting coverage for normal
24 x 36 mm shots with lenses of 35 mm focal length and
longer.
A wide-angle diffuser ቩ (identified by W) is included so
that the flash unit can also be used to cover the image
angle of a 24 mm lens.
A telephoto attachment
ቩ
(identified by T) is included for
telephoto lenses of 85 mm focal length and longer.
Please note that the effective range of the flash
light is diminished by use of a wide-angle diffuser,
and increased with a telephoto attachment!
Mounting/removing the attachments
Insert the wide-angle diffuser
ቩ
or telephoto attachment
in a swivelled out state (see fig.7) in the bayonet mount.
Turn the attachment clockwise to insert in the guide strip
in the housing gap.
To remove turn the attachment out of the retaining springs
(see fig.7) and withdraw.
Lighting and diffuser
Illuminazione e diffusori
Iluminación y Difusor
guiding strip
guida
través de la guía
housing gap
fessura del corpo
carcasa del flash
Fig. 7
Fig. 7
Fig. 7
☞
