ITEM MODEL PC24EK PC30EK PC36EK PC42EK PCH24EK PCH30EK PCH36EK PCH42EK
Cooling *1 BTU/h 24,000 31,000 36,500 42,500 24,000 30,000 35,400 42,000
Capacity Heating *1 BTU/h — — — — 27,000(33,500) 33,000(41,500) 38,000(47,600) 43,000(52,600)
Heating *2 BTU/h — — — — 18,400(24,900) 18,000(26,500) 19,600(29,200) 24,800(34,400)
Power Cooling *1 kW 2.43 3.1 3.8 4.4 2.46 3.06 3.53 4.37
Consumption Heating *1 kW — — — — 2.42(4.32) 3.13(5.63) 3.4(6.2) 4.3(7.1)
Heating *2 kW — — — — 2.1(4.0) 2.6(5.1) 2.7(5.5) 3.2(6.1)
EER *1 9.9 10.0 9.6 9.7 9.8 9.8 10.0 9.6
SEER 10.3 10.4 10.2 10.0 10.3 10.0 10.4 10.0
HSPF — — — — 7.1 7.1 7.4 7.3
COP Heating *1 — — — — 3.3 3.1 3.3 3.1
Heating *2 — — — — 2.6 2.4 2.1 2.3
INDOOR UNIT PC24EK PC30EK PC36EK PC42EK PCH24EK PCH30EK PCH36EK PCH42EK
External Finish Munsell 2.5Y 8/0.3 & N2
Power Supply V, phase, Hz 115, 1, 60 230, 1, 60
Max. Fuze Size (time delay) A 15 15 15 15 20 25 25 25
Min. Ampacity 3 3 3 3 12 15 15 17
Fan Motor F.L.A. 1.8 1.8 2.1 2.4 0.7 0.7 1.3 1.3
Auxiliary Heater A (kW) — — — — 8.4(1.9) 10.8(2.5) 12(2.8) 12(2.8)
Airflow Hi-Lo Dry CFM 1,050-850 1,050-850 1,270-990 1,270-990 920-740 920-740 1,270-990 1,270-990
Wet CFM 900-730 900-730 1,100-860 1,100-860 830-670 830-670 1,100-860 1,100-860
Moisture Removal Pints/h 7.2 9.6 11.1 12.6 7.0 9.1 10.9 12.3
Sound Pressure Level Hi-Lo dB(A) 50-43 50-43 52-44 52-44 50-43 50-43 51-45 51-45
Cond. Drain Connection OD in. 1 1 1 1 1 1 1 1
W in. 50-7/16 50-7/16 62-1/4 62-1/4 50-7/16 50-7/16 62-1/4 62-1/4
Dimensions D in. 26-13/16 26-13/16 26-13/16 26-13/16 26-13/16 26-13/16 26-13/16 26-13/16
H in. 10-1/8 10-1/8 10-1/8 10-1/8 10-1/8 10-1/8 10-1/8 10-1/8
Weight lbs. 93 93 115 115 97 97 119 119
OUTDOOR UNIT PU24EK PU30EK PU36EK PU42EK PU24EK PU30EK PU36EK PU42EK
External Finish Munsell 5Y 7/1
Sound Pressure Level dB(A) 55 55 55 56 55 55 55 53
Power Supply V, phase, Hz 230, 1, 60
Max. Fuze Size (time delay) A 20 30 30 40 20 30 30 40
Min. Ampacity 16 20 22 27 16 20 22 27
Fan Motor F.L.A. 0.65+0.65 0.65+0.65 0.75+0.75 0.8+0.8 0.65+0.65 0.75+0.75 0.75+0.75 0.8+0.8
Model (Type) NH33NBD NH41NAD NH47NAD NH569NXA NH33NBD NH41NAD NH47NAD NH569NXA
Compressor R.L.A.11.5 14 17.5 20 11.5 14 17.5 20
L.R.A.54 73 87 105 54 73 87 105
Crankcase Heater A(W) .17(39) .17(39) .17(39) .17(39) .17(39) .17(39) .17(39) .17(39)
Refrigerant Control Capillary Tube
Defrost method — — Reverse Cycle
W in. 34-1/4 34-1/4 38-3/16 38-3/16 34-1/4 38-3/16 38-3/16 38-3/16
Dimensions D in. 11-5/8 11-5/8 13-9/16 13-9/16 11-5/8 13-9/16 13-9/16 13-9/16
H in. 49-9/16 49-9/16 49-9/16 49-9/16 49-9/16 49-9/16 49-9/16 49-9/16
Weight lbs. 207 208 220 260 202 245 246 268
REMOTE CONTROLLER With Indoor Unit
Control Voltage (by built- in transformer) Indoor unit-remote controller: DC 12V, Indoor unit-outdoor unit: DC 12V
18
Figures in parentheses include auxiliary heat.
* For 208 volt applications refer to
Technical And Service Manual for ratings.
