BOAT COMPONENTS
23
TRANSOM VIEW
24164
a
b
c
d b
a - Drain valve (plug type
valve shown)
b - Towing holes
c - Motor plate
d - Manufacturer's plate
SIDE VIEW
b
a d
KEEP CLEAR! MAXIMUM OPEN PRESSURE 0.33 BAR/4.8 PSI/33 KPA MINIMUM RESET PRESSURE 0.28 BAR/4.1 PSI/28 KPA REFER TO OWNER MANUAL FOR INSTRUCTIONS
O VE RP RESSU R E
S EC URITY VAL VE
c
Model 380 shown
a - Paddle
b - Air chamber valves
c - Overpressure valve ‑
Hypalon models only
d - Keel air chamber valve
