BOAT COMPONENTS
21
TRANSOM VIEW
a
b
c
d
b
24161
a - Drain valve (plug type
valve shown)
b - Towing holes
c - Motor plate
d - Manufacturer's plate
SIDE VIEW
a
b c
24162
Model 380 shown
a - Paddle
b - Air chamber valves
c - Keel air chamber valve
