OM-232 368 Page 42
SECTION 9 − PARTS LIST
9-1. Drive Roll And Wire Guide Kits
.
Base selection of drive rolls upon the following recommended usages:
1 V-Grooved rolls for hard wire.
2 U-Grooved rolls for soft and soft shelled cored wires.
3 U-Cogged rolls for extremely soft shelled wires (usually hard surfacing types).
4 V-Knurled rolls for hard shelled cored wires.
5 Drive roll types may be mixed to suit particular requirements (e.g. V-Knurled
roll in combination with U-Grooved).
Wire Diameter
Kit No.
Drive Roll
Inlet Wire
Guide
Fraction Decimal Metric
Kit No.
Part No. Type
Inlet Wire
Guide
.023/.025 in. .023/.025 in. 0.6 mm 087 131 087 130 V-Grooved 056 192
.030/.035 in. .030/.035 in. 0.8/0.9 mm 204 579 203 526 V-Grooved 056 192
.030 in. .030 in. 0.8 mm 079 594 053 695 V-Grooved 056 192
.035 in. .035 in. 0.9 mm 079 595 053 700 V-Grooved 056 192
.
A complete Parts List is available at www.MillerWelds.com
