Metra Electronics 99-7878B User Manual
Page 6
99-7878B KIT ASSEMBLY
4
A
B
C
DIN MOUNT RADIO PROVISION WITH POCKET
Locate the factory wiring harness in
the dash. Metra recommends using
the proper mating adapter from Metra
or AXXESS. Re-connect the negative
battery terminal and test the unit for
proper operation.
1
Slide the DIN cage into the Radio
Housing and secure by bending the
metal locking tabs down. (Figure A)
2
Snap the pocket into the bottom
opening of the radio housing.
(Figure B)
3
Slide the aftermarket head unit into
the cage and secure. (Figure C)
4
Reassemble dash in reverse order of
disassembly.
5
*
Note: Refer also to the instructions included with the aftermarket radio.
