17 English
BATTERIE
S
AN
D
CHAR
GER
S
When acquiring additional chargers or power
supplies, make sure you have similar drop-in
tray chargers and power supplies set. For part
number details refer to “Chargers” on page 65.
Installing Spring Action Belt Clip
1. Slide the spring action belt clip rails into the belt
clip grooves on the back of the battery pack
and slide it down until the belt clip tab snaps
into place.
2. To remove, pull back the metal release tab on
the belt clip tab and push the spring action belt
clip upward to remove.
Battery Life Information
Li-Ion Battery Life
Depending on the radio model and/or region
the battery capacity will be different. This
feature will determine the estimated battery
life. When the Battery Save feature is ON
(enabled by default) the battery life will be
longer.
belt clip tab
Spring
Action Belt
Clip
