DCA-85USJ — OPERATION AND PARTS MANUAL — REV. #0 (09/17/04) — PAGE 79
1
DCA-85USJ — ENCLOSURE #2 ASSY.
ENCLOSURE #2 ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M3443000802 REAR FRAME ................................................. 1 ............ S/N 8400001 TO 8400020
1 M3443000812 REAR FRAME ................................................. 1 ............ S/N 8400021~
1A M3493303203 ACOUSTIC SHEET 1
2 M3443000904 DUCT ............................................................... 2 ............ S/N 8400001 TO 8400020
2 M3443000914 DUCT ............................................................... 2 ............ S/N 8400021~
2A M3493303304 ACOUSTIC SHEET 2
3 0016908020 HEX, HEAD BOLT 26
4 0016910025 HEX, HEAD BOLT 4
5 M2443300903 COVER, REAR FRAME 1
5A M2493302204 ACOUSTIC SHEET 1
6 0016908020 HEX, HEAD BOLT ......................................... 13 ............ S/N 8400001 TO 8400030
6 0019208020 HEX, HEAD BOLT ......................................... 13 ............ S/N 8400031~
7 M3443200503 DOOR, REAR FRAME 1
8 M3443600304 WINDOW PLATE 1
9 0207306000 HEX, NUT 8
9A 0041206000 PLAIN WASHER 8
10 M9113000002 DOOR HANDLE ASSY. 1
11 0021806016 MACHINE SCREW 4
11A 0030006000 HEX, NUT 4
12 M9110100204 HINGE 2
13 M9116100004 WASHER 2
14 0016908020 HEX, HEAD BOLT ........................................... 3 ............ S/N 8400001 TO 8400030
14 0019208020 HEX, HEAD BOLT ........................................... 3 ............ S/N 8400031~
15 M2453200602 SPLASHER PANEL ......................................... 1 ............ S/N 8400001 TO 8400030
15 M2453200612 SPLASHER PANEL ......................................... 1 ............ S/N 8400031~
15A M2493404604 ACOUSTIC SHEET ......................................... 1 ............ S/N 8400001 TO 8400030
15A M2493404614 ACOUSTIC SHEET ......................................... 1 ............ S/N 8400031~
16 0016908065 HEX, HEAD BOLT ........................................... 4 ............ S/N 8400001 TO 8400030
16 0019208065 HEX, HEAD BOLT ........................................... 4 ............ S/N 8400031~
THE SERIAL NUMBER MAY BE REQUIRED.
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
1-ORANGE 5-BLACK
2-WHITE 6-CATERPILLAR YELLOW
3-SPECTRUM GREY 7-CATO GOLD
4-SUNBELT GREEN 8-RED
