Do not separate the soft-close
mechanism from the ball joint. This
would damage the mechanism.
^ Stand the appliance doors up one by
one, and slacken the hinges at the
front (the hinges remain open).
^ Remove caps a from the top and
bottom of each door (if the caps are
not in place, they will have been
supplied separately with the
appliance).
^ Remove screws b from all of the
hinges, and refit each hinge in its
diagonally opposite corner.
Do not close up the hinges. Danger
of injury.
^ Use a powered screwdriver to secure
the hinges; screws
b are
self-tapping.
^ Replace caps a in the vacant holes
on the opposite side.
To secure the soft-close mechanism
^ Place the two doors with the outer
side downwards on a stable surface.
^ Screw ball joints b of soft-close
mechanism
c into the new fixing
hole.
^ Open out soft-close mechanism c,
and hook mounting
a onto the hinge.
^ Hold the soft-close mechanism in this
position, and screw mounting
a to
the hinge.
Changing the door hinging
