1.3 Explanation of Basic Concepts and Symbols 1
Di2010/Di2510/Di3010/Di3510 1-5
Int
ro
duc
tio
n
Chap
ter
1
“Width” and “Length”
Whenever paper dimensions are mentioned in
this manual, the first value always refers to the
width of the paper (shown as “Y” in the
illustration) and the second to the length (shown
as “X”).
Paper Orientation
Lengthwise ( )
If the width (Y) of the paper is shorter than the
length (X), the paper has a vertical or portrait
orientation, indicated by either “L” or
.
Crosswise ( )
If the width (Y) of the paper is longer than the
length (X), the paper has a horizontal or
landscape orientation, indicated by either “C”
or
.
Portrait and Landscape
Portrait
With the “portrait” orientation, the paper is vertical, like a portrait.
Landscape
With the “landscape” orientation, the paper is horizontal, like a
landscape.
