Marshall electronic V-LCD15SB-AFHD-DT - Manual (Page 2)

2
Contents
Product Overview..................................................................................................................................................... 3
Features .................................................................................................................................................................... 3
Installation and Initial Setup ................................................................................................................................... 4
Unpacking .............................................................................................................................................................. 4
Installation .............................................................................................................................................................. 4
Connections and Power-On................................................................................................................................... 4
Front Panel Features ............................................................................................................................................... 5
Power Button ........................................................................................................................................................ 5
Input Select Buttons............................................................................................................................................... 5
On-Screen Menu Navigation Buttons .................................................................................................................... 5
User-Definable Function Buttons........................................................................................................................... 5
Image Adjustment Knobs....................................................................................................................................... 5
Tally Lights............................................................................................................................................................. 5
Rear Panel Features................................................................................................................................................. 6
Power Input............................................................................................................................................................ 6
Signal Input/Output ................................................................................................................................................ 6
Tally Interface ........................................................................................................................................................ 6
Mounting Holes ...................................................................................................................................................... 6
Compatible Input Formats....................................................................................................................................... 7
On-Screen Menu....................................................................................................................................................... 8
STRUCTURE OVERVIEW .................................................................................................................................... 8
MAIN MENU AND NAVIGATION .......................................................................................................................... 8
MARKER SETUP SUBMENU ............................................................................................................................... 9
16:9 Markers...................................................................................................................................................... 9
4:3 Markers...................................................................................................................................................... 10
Marker Background ......................................................................................................................................... 10
Center Marker.................................................................................................................................................. 10
VIDEO CONFIGURATION SUBMENU ............................................................................................................... 11
Color Temperature Presets ............................................................................................................................. 11
Adjusting Color Bias ........................................................................................................................................ 11
Adjusting Color Gain........................................................................................................................................ 11
Monochrome Mode.......................................................................................................................................... 12
Blue Only Mode ............................................................................................................................................... 12
Pixel-to-Pixel
™ Mode ...................................................................................................................................... 12
Aspect Ratio Setting ........................................................................................................................................ 13
Scanning Modes.............................................................................................................................................. 13
Delay Modes.................................................................................................................................................... 13
SYSTEM CONFIGURATION SUBMENU............................................................................................................ 14
Internal SMPTE Color Bars ............................................................................................................................. 14
User-Definable Function Buttons .................................................................................................................... 14
Status Display.................................................................................................................................................. 14
Saving and Loading User Configuration Presets ............................................................................................ 14
Specifications ......................................................................................................................................................... 15
Maintenance............................................................................................................................................................ 16
Warranty.................................................................................................................................................................. 16
15
Specifications
■ PANEL
Screen Size 15.0” Diagonal
Display Area (h x v) 304.128 x 228.096 mm
Aspect Ratio 4:3 Native (4:3/16:9 Modes)
Pixels 1024 x RGB x 768
Color Depth 16,777,216 Colors
Viewing Angle (h x v) 160° x 140°
Brightness 600 cd/m
2
Contrast Ratio 600:1
Dot Pitch (h x v) 0.099 x 0.297 mm
Pixel Pitch (h x v) 0.297 x 0.297 mm
Pixel Response 18 ms (rise + fall)
■ VIDEO INPUT/OUTPUT
Video Input / Output
Supports SMPTE 170M, NTSC/PAL
Color burst/sub-carrier required
S-Video (Y/C) Input / Output
Supports SMPTE 170M, NTSC/PAL
YP
B
P
R
Input / Output
Supports SMPTE 260M, 274M, 296M
HD-SDI Input / Output
Supports ITU-R BT.656, SMPTE 259M. 292M
VGA Input
Supports RGBHV, RsGsBs, RGsB, RGB CS,
DVI Input
Supports Digital Signals Only (DVI-D)
HDCP Supported
■ CONNECTORS
Video Input
Video
1 x BNC Female (75 Ω)
S-Video (Y/C) 1 x 4-Pin Mini-DIN
YP
B
P
R
3 x BNC Female (75 Ω)
HD-SDI 1 x BNC Female (75 Ω)
VGA 1 x HD-15 Female
DVI 1 x DVI-I 29-Pin Female
Video Output (Active Loop-Through)
Video
1 x BNC Female (75 Ω)
S-Video (Y/C) 1 x 4-Pin Mini-DIN
YP
B
P
R
3 x BNC Female (75 Ω)
SDI 1 x BNC Female (75 Ω)
Power Input
2-Pin Conxall Twist-Lock Female
Tally Interface
HD-15 Female
■ TALLY
3 LEDs (Green, Red, Yellow). Activation requires contact
closure of pin to ground on the HD-15 connector:
Pin No. Signal
1 Green
2 Red
3 Yellow
4 Ground
5 Ground
6 N/C
7 N/C
8 N/C
9 N/C
10 N/C
11 N/C
12 N/C
13 N/C
14 Ground
15 Ground
■ ELECTRICAL
Power Consumption 3A @ 12VDC (36 W)
Voltage Requirement 12-14 VDC
V-PS12-5V-1 Power Supply:
Input 100V-240V, 50/60Hz
Output 12-14V, 5A
■ MECHANICAL
Dimensions (w x h x d): 15.25” x 10.45” x 1.77”
Height with Stand:
11.01”
Rack Height: 6 RU
Additional Mounting: VESA 75 mm
Weight (Monitor Only): 8.1 lbs
Operating Temperature 32°F to 120°F (0°C to 50°C)
Storage Temperature
-4°F to120°F (-20°C to 50°C)
Compliance
₠, FCC-Class A, ANSI-63.4
(Certificates on file)
RoHs Do not dispose. Return to
Manufacturer or Authorized
Recycle Facility.
