14
Air exhaust
Air exhaust direction can be changed easily by rotating the
exhaust cover. Change it when necessary.
Jammed nailer
CAUTION:
•
Always disconnect the hose before cleaning a jam.
When the nailer becomes jammed, do as follows:
Use pliers to bend the jammed nail so that the nail head
comes out of the nail guide. Then remove the jammed nail.
After removing the jammed nail, make sure that the nail
guide and the contact arm move smoothly.
Hook
The hook is convenient for hanging the tool temporarily. This
hook can be installed on either side of the tool.
To remove the hex wrench 3 from the hook, press up on the
end of the hex wrench as shown in the figure.
CAUTION:
•
Always disconnect the hose when hanging the tool using
the hook.
•
Always tighten the hook securing bolt firmly.
•
Never hang the tool on a waist belt or the like.
Dangerous accidental firing may result.
Nails
Avoid storing nails in a very humid or hot place or place
exposed to direct sunlight.
Exhaust cover
Pliers
Nail guide
Nail
Hook
Hex wrench 3
Press up
