Manitowoc Ice G-1700 - Manual

ICE CUBERS
T ICE DISPENSERS T ICE STORAGE BINS
REACH-IN REFRIGERATORS & FREEZERS
ISO 9001 Quality System Certified
MANITOWOC EQUIPMENT WORKS
Division of The Manitowoc Company, Inc. l 2110 South 26th Street, P.O. Box 1720, Manitowoc, WI 54221-1720 U.S.A.
( 414-682-0161 l FAX 414-683-7879
G-1700, 60 HZ., 1 PHASE COMPRESSOR, 7622153
REPLACEMENT INSTRUCTIONS
1. Remove the old compressor. Unsweat all tubes from the old compressor. Do
not cut them off.
2. Place the new compressor into the ice machine, as shown.
3. This replacement compressor may be different than the original compressor
and/or have slightly different tubing configurations. The suction line,
discharge line, and/or suction service line at the compressor may need to be
rerouted, when making this change-out.
4. Replace the compressor components (start relay, start capacitor, and run
capacitor) with the new ones provided. NOTE: The new start relay must be
mounted in the position shown.
5. Replace the filter drier with the new drier, as called out in the parts manual.
6. Evacuate the ice machine following the steps on the service bulletin.
7. Charge the ice machine with the nameplate charge.
8003453
Revised 10/26/95
