Replacing the fuses under the hood
If the headlights or other electrical
components don't work and the fuses in
the cabin are OK, inspect the fuse block
under the hood. If a fuse is blown, it must
be replaced. Follow these steps:
1. Turn off the ignition switch and all
other switches.
2. Remove the fuse block cover.
Next to air filter
Engine cover
Near battery
Battery cover
NOTE
Remove the engine and battery covers
before removing the fuse block cover
near the battery.
3. If a fuse is blown, replace it with a new
one of the same amperage rating.
Normal Blown
NOTE
l To replace the MAIN fuse, contact
an Authorized Mazda Dealer (page
8-41).
l Verify that the engine cover is
securely installed.
8-40
Maintenance and Care
Owner Maintenance
