NOTE
l If the halogen bulb is accidentally
touched, it should be cleaned with
rubbing alcohol before being used.
l Use the protective cover and carton
of the replacement bulb to dispose of
the old bulb promptly out of the
reach of children.
qReplacing a Fog Light Bulb í
Due to the complexity and difficulty of
the procedure, the bulbs should be
replaced by an Authorized Mazda Dealer.
qReplacing a Bulb (Front)
1. If you are changing the right bulb, start
the engine, turn the steering wheel all
the way to the right, and turn off
engine. If you are changing the left
bulb, turn the steering wheel to the left.
2. Turn the center section of the plastic
retainer counterclockwise and remove
the retainers and partially peel back the
mudguard.
Removal
Installation
Front turn signal lights, Parking lights,
Front side-marker lights
1. Turn the socket and bulb assembly
counterclockwise and remove it.
2. Disconnect the bulb from the socket.
Front turn signal
lights
Parking lights
Front side-marker lights
3. Install the new bulb in the reverse order
of removal.
Maintenance and Care
Owner Maintenance
8-35 í
Some models.
