Page 24

OM-230 298 Page 20
Tools Needed:
1/4 in
4-17. Equipment DIP Switch Settings (For Models With Meters Only)
12
3
4
5
Inches/Minute
Digital Meter DIP Switch Setting
Ref. 803 154
Remove wrapper.
1
DIP Switch S2 On Digital
Meter Board PC60
Install wrapper when finished.
12
3
4
5
Meters/Minute
PC60
1
SECTION 5 − OPERATION
5-1. Operational Terms
The following is a list of terms and their definitions as they apply to this wire feeder:
General Terms:
Cold Wire Jog
Feeding wire without contactor or gas valve being energized.
