Appendix 55
DSP5000 User Guide
Appendix 1 DSP5000 types
Type 1 setup, Meridian 500 series system using 562
The Meridian 562 allows simple control and routing of analogue and digital
sources. All connections from sources are made to 562 which then sends
a single digital feed to the DSP5000s. Type 1 sets the DSP5000 as a left
master, so you will need to make the other a right slave, or adjust left/right
on both speakers.
Type 1 500 500, 506, 508
Remote key Logo Input on
DSP5000 Control? Address
CD cd D1 1C 1A
Radio rd D1 2C 1A
LP LP D1 NC 1A
Video tn D1 NC 1A
Tape 1 t1 D1 NC 1A
Tape 2 t2 D1 NC 1A
CDR Cr D1 1C 1A
Cable Cb D1 NC 1A
Text tt D1 NC 1A
VCR1 U1 D1 NC 1A
VCR2 U2 D1 NC 1A
LaserDisc Ld D1 5C 1A
