SECTION 2 INSTALLATION
2-4 SECTION 2, INSTALLATION
If possible, mount the Wireless Ethernet Bridge to concrete,
masonry, a wooden stud, or other solid wall material. Use
anchors if necessary; for example if you must mount the unit on
drywall. Mounting the unit on the wall may decrease performance.
To mount your Wireless Ethernet Bridge on the wall:
1 Print the Wall Mounting Template.
3.15
[80.00]
INPUT VOLTAGE: +5VDC, 2A
FCC ID: F2NWE800G
FOR HOME OR OFFICE USE
Tested To Comply
With FCC Standards
MODEL: WE800G
WIRELESS MAC: AB CD EF 01 23 45
MADE IN TAIWAN
MODEL WE800G
PART NUMBER: AAAAAA-BBB-CC
S/N: PPPPMMYJJJSSSSSCAABBCCCC
The illustration is drawn at a one-to-one scale, which means that
when printed, it provides the exact dimensions required to mount
the unit.
2 Click the Print icon or choose Print from the File menu to display
the Print dialog box. (A sample print dialog appears below.)
Be sure you print the template at 100% scale and that Fit to page is
not checked in the Print dialog box.
