OPERATION
14 F–030610L
Figure 4
Throttle Control
Lever
Blade Rotation
Control
Clutch / Brake
Pedal
Lift Lever Shift Lever
LOCATION OF CONTROLS
BLADE ROTATION CONTROL:
Use the blade rotation
control to start and stop the rotation of the blade.
CLUTCH / BRAKE PEDAL:
The pedal has two functions.
The first function is a clutch. The second function is a brake.
IGNITION SWITCH:
Use the ignition switch to start and stop
the engine.
SHIFT LEVER:
Use the shift lever to change the speed of the
unit.
LIFT LEVER:
Use the lift lever to change the height of cut.
PARKING BRAKE LEVER:
Use the parking brake lever
to engage the brake when you leave the unit.
THROTTLE CONTROL LEVER:
Use the throttle control
lever to increase or decrease the speed of the engine.
