PCI-QUAD-AC5 User's Guide
Specifications
P3
Pin
Signal Name
Pin
Signal Name
1
THIRD PORT C Bit 7
2
GND
3
THIRD PORT C Bit 6
4
GND
5
THIRD PORT C Bit 5
6
GND
7
THIRD PORT C Bit 4
8
GND
9
THIRD PORT C Bit 3
10
GND
11
THIRD PORT C Bit 2
12
GND
13
THIRD PORT C Bit 1
14
GND
15
THIRD PORT C Bit 0
16
GND
17
THIRD PORT B Bit 7
18
GND
19
THIRD PORT B Bit 6
20
GND
21
THIRD PORT B Bit 5
22
GND
23
THIRD PORT B Bit 4
24
GND
25
THIRD PORT B Bit 3
26
GND
27
THIRD PORT B Bit 2
28
GND
29
THIRD PORT B Bit 1
20
GND
31
THIRD PORT B Bit 0
32
GND
33
THIRD PORT A Bit 7
34
GND
35
THIRD PORT A Bit 6
36
GND
37
THIRD PORT A Bit 5
38
GND
39
THIRD PORT A Bit 4
40
GND
41
THIRD PORT A Bit 3
42
GND
43
THIRD PORT A Bit 2
44
GND
45
THIRD PORT A Bit 1
46
GND
47
THIRD PORT A Bit 0
48
GND
49
+5V Out
50
GND
P4
Pin
Signal Name
Pin
Signal Name
1
FOURTH PORT C Bit 7
2
GND
3
FOURTH PORT C Bit 6
4
GND
5
FOURTH PORT C Bit 5
6
GND
7
FOURTH PORT C Bit 4
8
GND
9
FOURTH PORT C Bit 3
10
GND
11
FOURTH PORT C Bit 2
12
GND
13
FOURTH PORT C Bit 1
14
GND
15
FOURTH PORT C Bit 0
16
GND
17
FOURTH PORT B Bit 7
18
GND
19
FOURTH PORT B Bit 6
20
GND
21
FOURTH PORT B Bit 5
22
GND
23
FOURTH PORT B Bit 4
24
GND
25
FOURTH PORT B Bit 3
26
GND
27
FOURTH PORT B Bit 2
28
GND
29
FOURTH PORT B Bit 1
20
GND
31
FOURTH PORT B Bit 0
32
GND
33
FOURTH PORT A Bit 7
34
GND
35
FOURTH PORT A Bit 6
36
GND
37
FOURTH PORT A Bit 5
38
GND
39
FOURTH PORT A Bit 4
40
GND
41
FOURTH PORT A Bit 3
42
GND
43
FOURTH PORT A Bit 2
44
GND
45
FOURTH PORT A Bit 1
46
GND
47
FOURTH PORT A Bit 0
48
GND
49
+5V Out
50
GND
5-3
