MITSUBISHI ELECTRIC 1554R - Manual (Page 17)

9
Specifications
Picture Tube
Size
Type
Dot pitch
Surface coating
15” (38.1cm) diagonal
FST
0.28mm
AG, AS coating
Maximum Viewable Size 13.9” (35.4cm) diagonal
Power Supply (Universal)
Input voltage
Power consumption(Max.)
100~240 V AC, 50~60 Hz (Universal)
75 w
Max. Resolution
1024 x 768
Horizontal Frequency
30-54 KHz
Vertical Frequency
50-120 Hz
Video Bandwidth
65 MHz
Video Input
mini D-sub connector
Adjustable Timing
6 factory presets, 10 user modes
User’s Control
Digital control
Regulatory Compliance
UL,CSA,C-Tick, MPR II
Plug & Play
DDC1/2B
Ambient Temperature
Operating
Storage
+5
°C ~ +40°C / +41°F ~ +104°F
-20
°C ~ +60°C / -4°F ~ +140°F
Humidity
Operating
Storage
20% ~ 90%
10% ~ 90%
Dimensions (W x H x D)
361 mm (W) x 388 mm (H) x 384 mm (D)
Weight (net)
12.0 Kg
5
