5
Adjusting the Monitor
Control Functions
The monitor digital control functions are located on the front panel (see the illustration
below). They are described in the following sections.
1. Power Switch
Pincushion
Horizontal Size
2. Adjust
Vertical Center
Contrast
3. Select
Vertical Size
Brightness
Trapezoid
Horizontal Phase Rotation
3
