Select / Adjust
Press the SELECT
+
or
-
button to cycle through the adjustment options to choose
H-Phase, H-Size, V-Center, V-Size, Contrast, Brightness, Trapezoid, Pincushion and
Rotation. And then press ADJUST
+
or
-
button to change the settings.
Recall
Recall all settings to factory defaults by pressing both function keys of SELECT
+
and
ADJUST
-
.
Timing Setting
By making adjustments of your video card settings, you can set the timing and the refresh
rate to your preferences. The monitor will automatically save the settings. Your monitor
can accept horizontal frequencies ranging from 30 KHz to 54 KHz and vertical
frequencies from 50 Hz to 120 Hz. However, due to different resolution requirements,
do not exceed the following maximum vertical refresh rates to avoid possible damage to
your monitor.
Resolution Maximum Vertical
Refresh Rate (Hz)
640 x 480 100
800 x 600 86
1024 x 768 67
Factory Preset Timings
Mode Resolution Vertical
Frequency (Hz)
Horizontal
Frequency (KHz)
Industry 640 x 400 70 31.47
Industry 640 x 480 60 31.47
VESA 640 x 480 75 37.50
VESA 800 x 600 75 46.88
VESA 800 x 600 85 53.67
VESA 1024 x 768 60 48.30
