23
ENGLISH
ENGLISH
OTHER FUNCTION
TV AUTO ON/OFF FUNCTION
This function allows the component connected to
the TV-VIDEO in jack to control the power (ON/
OFF) to the SR6400.
AUTO POWER ON
1. Be sure the TV auto mode is ENABLED.
(Refer page 17 : System Setup)
2. Connect your TV TUNER (etc) to the TV-VIDEO
in terminal. Be sure to connect the VIDEO input.
3.
Turn OFF the power to the TV TUNER and the
SR6400.
4. Turn ON the TV TUNER and tune in a receivable
station.
5.
When the station is received, the SR6400
turns ON and TV is selected automatically.
AUTO POWER OFF
1. In the above situation, turn the TV TUNER
OFF or select a channel that does not contain
any broadcast.
2. The power to the SR6400 switches to STANDBY
after approx. 5 minutes.
Notes:
• AUTO POWER OFF is canceled if the SR6400 is
set to a source other than TV.
The function reactivates when TV is selected again.
• Some TV broadcasts may cause the TV AUTO
FUNCTION to turn ON.
• The S-Video terminal does not support “TV AUTO
ON/OFF” function.
ATTENUATION TO ANALOG INPUT
SIGNAL
If the selected analog audio input signal is greater
than the capable level of internal processing, the
“PEAK” indicator will light up on the front display.
If this happens, you should press the ATT button
on the front panel or on the remote.
“ATT” indicator will be illuminated when this
function is activated. The signal-input level is
reduced by about half. Attenuation will not work
with the output signal of TAPE-OUT, CD-R/MD-
OUT, VCR1-OUT and DSS/VCR2-OUT.
This function is memorized for each individual
input source.
LISTENING THROUGH HEADPHONES
This jack may be used to listen to the SR6400’s
output through a pair of headphones. Be certain that
the headphones have a standard 1/4" stereo phono
plug. (Note that the speakers will automatically be
turned off when the headphone jack is in use.)
Notes:
• When using headphones, the surround mode will
change to STEREO and TruSurround (TS)
headphones by SURROUND MODE selector.
• The surround mode returns to the previous setting
as soon as the plug is removed from the jack.
VIDEO ON/OFF
When no video signal is connected to the SR6400
or a DVD, etc., is connected directly to your TV, the
unnecessary video circuit can be turned off by
selecting the “VIDEO OFF” setting.
To select video off, press the V-OFF on the remote.
DISPLAY MODE
You can select the display mode for the front display
of the SR6400.
To select this mode, press the DISP. on the remote
control.
When this button is pressed, the display mode is
switched in the following sequence.
→ Surround Mode → Auto-display Off → Display
Off
→ Input Function → Surround Mode....
In Auto display off mode, the display is off. But, if
you make a change to the unit such as input or
surround mode, the display will show that change,
then go back to off after about 3 seconds. When
changing the volume, it is not displayed.
In Display off mode, the display is off completely.
Notes:
• Only the DISP indicator will be illuminated on the
front display in display off condition
AV SURROUND RECEIVER SR6400 SELECTOR
MEMORY TUNING CLEAR
POWER ON/STANDBY PHONES
ENTER
STANDBY
SELECT
DSS/VCR2 AUX VCR1 DVD TV
A/D 6.1CH INPUT SPEAKERS A/B
UP
VOLUME
DOWN MODE
MUTE
AUX INPUT S-VIDEO VIDEO L AUDIO R
ATT
CD CD-R TAPE TUNER
S-DIRECT DISPLAY
F/P
UND RECEIVER SR6400
MEMORY TUNING MODE CLEAR
ONES
TER
DSS/VCR2 AUX VCR1 DVD TV CD CD-R TAPE TUNER
S-DIRECT DISPLAY A/D 6.1CH INPUT SPEAKERS A/B
F/P
DISP MULTI AUTO TUNED ST V – OFF NIGHT PEAK ANALOG DIGITAL ATT SLEEP SURR AUTO DIRECT DISC 6.1 MT X 6.1 SPKR A B EQ DIGITAL SURROUND
PCM L C R SL S SR LFE
AV SURROUND RECEIVER SR6400
MEMORY TUNING CLEAR
PHONES
ENTER
DSS/VCR2 AUX VCR1 DVD TV CD CD-R TAPE
S-DIRECT A/D 6.1CH INPUT SPEAKERS A/B
F/P
DISP MULTI AUTO TUNED ST V – OFF NIGHT PEAK ANALOG DIGITAL ATT SLEEP SURR AUTO DIRECT DISC 6.1 MT X 6.1 SPKR A B EQ DIGITAL SURROUND
PCM L C R SL S SR LFE
SELECTING ANALOG AUDIO INPUT
OR DIGITAL AUDIO INPUT
If you have already assigned the digital inputs, you
can temporarily select the audio input mode for
each input source with the A/D button on the remote
controller or front panel.
When this button is pressed, the input mode is
switched in the following sequence.
→ Digital Auto → Digital → Analog → Digital Auto....
In Digital Auto mode, the types of signals being
input to the digital and analog input jacks for the
selected input source are detected automatically.
If no digital signal is being input, the analog input
jacks are selected automatically.
In Digital mode, input is fixed to an assigned digital
input terminal.
In analog mode, the analog input jacks are selected.
This selecting is temporary, so the result will not be
stored in memory.
If you need to change the input mode completely,
use SYSTEM SETUP in OSD menu system. (see
page 16)
