25
At a glance
Instrument cluster
Item Page
1 Speedometer with:
v Electronic Stability
Program (ESP)
warning lamp
79,
306
; Brake warning
lamp, USA only
48,
54,
303
3 Brake warning
lamp, Canada only
48,
54,
303
B Low beam head-
lamp indicator lamp
49,
109
2 L Left turn signal
indicator lamp
50
3 Multifunction display
with:
121
Trip odometer 119
Main odometer 121
Gear selector lever
position 47,
121,
160
Item Page
Program mode 121,
162,
165
Status indicator (outside
temperature/digital
speedometer 119,
136
Digital clock 121
4 K Right turn signal
indicator lamp
50
5 Tachometer with: 119
- Antilock Brake
System (ABS)
indicator lamp
77,
302
ú Engine malfunction
indicator lamp,
USA only
304,
305
± Engine malfunction
indicator lamp,
Canada only
304,
305
1 Supplemental
restraint system
indicator lamp
58,
307
Item Page
< Seat belt telltale 64,
307
A High beam head-
lamp indicator lamp
50,
113
6 Fuel gauge with:
Fuel reserve warning lamp 307
4 Fuel filler cap
location indicator:
The fuel filler cap is
on the rear
right-hand side.
7 Coolant temperature
gauge
118
8 Reset button for: 117
ț Resetting trip
odometer 119
ț Resetting individual
settings 133
ț Instrument cluster
illumination 117
