Page 5
5
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the
Sun. Do not look through the telescope as it is moving.
Pedestal Assembly
MAX's Pedestal assembly can be configured to
cover three latitude ranges without the need of
disassembly. Together, the three ranges allow
the mount to operate anywhere on the planet.
PEDESTAL
(WEDGE)
ASSEMBLY
RA Lock
Knob
Latitude
Lock
Knobs (x4)
Dovetail
Ejector
Knob
Azimuth
Lock
Knobs (x5)
Azimuth
Adjustment
Knob
Latitude
Range
Bolts (8x)
Latitude
Scale
Azimuth
Adjust
Knob
Latitude
Adjust
Knob
Dovetail
Ejector
Knobs (2)
RA Female
Dovetail
Tripod/Pier
Interface
Plate
