Meade Instruments 20 MAX-ACF User Manual
Page 10
10
Looking at or near the Sun will cause irreversible damage to your eye. Do not point this telescope at or near the
Sun. Do not look through the telescope as it is moving.
Off/On
USB Port
AUX port
12vDC In
12VDC
Switched
12VDC
Switched
Out
HBX port
(Handbox
port)
Serial port
USB Ports
Reticle Port
Focuser
HBX port
Auto Guider
Smart Accessory Ports
CONTROL
PANELS
AND PORTS
RA ASSEMBLY
CONTROL
PANEL
SADDLE
CONTROL
PANEL
RA TO DEC
JUMPER CABLE
JUMPER CABLE
BETWEEN OTA
AND SADDLE
PANEL
(may use either of
the Smart
Accessory ports)
