33
Part 3: REPLACEMENT PARTS
WATER INLET PIPING
Fig. 3.11 Part
Item No. No.
Part Description Qty
1 100500 Vacuum Breaker 1/2" .................................................................... 1
2 108349 Repair Kit 1/2" .............................................................................. A/R
3 Bracket, Vacuum Breaker .............................................................. 1
4 C180312 Barb Fitting ................................................................................... 2
5
C450114 Clamp, Hose .................................................................................. A/R
6 C200104 Booster Hose ................................................................................. A/R
7 Nut ................................................................................................. 2
8 Washer ........................................................................................... 2
9 C280123 Street Elbow .................................................................................. 1
10 C290428 Barb Fitting ................................................................................... 1
11 C330756 Valve Bracket ................................................................................ 1
13 C121102 Valve Solenoid 240V .................................................................... 1
14 Repair Kit ...................................................................................... A/R
15 Coil ................................................................................................ A/R
16 C270308 Fitting ............................................................................................ 1
A Mounting Hardware for Valve Bracket
C260512
Washer, Lock ................................................................................. 2
C260538 Washer ........................................................................................... 2
110214 Nut, Dull M6 ................................................................................. 2
