27
Part 3: REPLACEMENT PARTS
WASH AND RINSE PIPING
Fig. 3.8 Part
Item No. No.
Part Description Qty
1 C190227 Spindle .......................................................................................... 2
2 C332526 Rinse Tube .................................................................................... 2
3 C200955 Gasket ............................................................................................ 2
4 C191100 Wash Manifold Upper ................................................................... 2
5 C450103 Clamp, Hose .................................................................................. A/R
6 107417 Hose .............................................................................................. A/R
7 0502651 Coupler, 1/2MPT x 1/2 Hose ........................................................ 2
8 C280312 Cross Fitting .................................................................................. 1
9 C290125 Hose Barb ...................................................................................... 1
10 C190320 ....................................................................................................... 1
11 C180130 ....................................................................................................... 14
12 C160117 Hose .............................................................................................. 1
13 C200482 O-ring, Wash Manifold (Not Shown) ........................................... 2
14 C201067 Discharge Pump Hose ................................................................... 1
15 C450119 Clamp, Hose .................................................................................. 2
16 C190674 Spacer, Wash Manifold Lower ...................................................... 1
A Hardware for Mounting Spindle (Quantities per Spindle)
C260151
Screw ............................................................................................. 1
C260510 Lock washer .................................................................................. 1
C260502 Washer ........................................................................................... 1
