QP2H CENTRIFUGAL PUMP • OPERATION AND PARTS MANUAL — REV. #0 (08/04/08) — PAGE 31
PUMP ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
GX120U1PX2
ENGINE, HONDA
1
2
7204100010
CASING
1
3
72040001600014
SUCTION COVER NPT2”
1
4
1889350351
CHECK VALVE
1
5
0181050820
BOLT SET WITH WASHER, LOCK M8X20
4
6
0191150520
BOLT
4
7%
0489242100
O-RING (CASING). DIA 2.4 X DIA. 210
1
8%
0489241780
O-RING (VOLUTE CASING)
1
9%
0803442320
MECHANICAL SEAL SILCON CARBIDE
1 SET
10%
0852831600
ADJUST LINER DIA. 0.3 THICKNESS
1~3
10%
0852851600
ADJUST LINER DIA. 0.5 THICKNESS
1~3
11
7204000030
IMPELLER 3/4”-16UNF
1
12
1808000130
VOLUTE CASING
1
13
1293330620
VOLUTE CASING PACKING
1
14
1211390610
CASING COVER PACKING
1
15
7204100020
CASING COVER
1
16
0181050825
BOLT SET WITH WASHER, LOCK
6
(DELIVERY ELBOW) M8 X 25
17
9246100090
DELIVERY ELBOW NPS2”
1
18
0181050820
BOLT SET WITH WASHER, LOCK
4
19
0631211100ASSY
FLOODING CAP PF1”
1
20
0480350300
O-RING (FLOODING CAP)
1
21
0481310550
O-RING (DELIVERY ELBOW)
1
22
0631211100ASSY
DRAIN CAP PF1”
1
23
0480350300
O-RING (DRAIN CAP)
1
24
7204214010P002
BASE
1
25
0105050840
BOLT (ENGINE) M8 X 40
4
26
0209150080
FLANGE NUT (ENGINE) M8
4
27
0723322030R
CUSHION RUBBER
4
28
0209150060
FLANGE NUT (CUSHION RUBBER) M6
4
29
07904320200014
NIPPLE (DELIVERY) NPS2” X NPT2”
1
30
0481310550
O-RING (NIPPLE)
1
31
0742303050
STRAINER NPT2”
1
32
0451250080
WASHER, LOCK M8
4
33
KIT204
KIT, PUMP .................................................................. 1 .......... INCLUDES ITEMS W/%
