REMOTE
1. REMOTE MODE
Set the remote mode for connection with computer via RS-232 or RS-485.
(Please refer to page. 23 for RS-232 Remote Control).
2. BAUD RATE
Set the remote protocol transmitting baud rate. Available options are 115200,
57600, 19200, 9600, 4800, 3600, 2400, 1200.
3. ID
To control different DMR by setting
remote protocol. ID number can be set
from 000 to 255.
(MENU)
TIMER
CAMERA
RECORD
ALARM
DWELL
PIP
MOTION
DISPLAY
REMOTE
USER
SYSTEM
EVENT
(REMOTE)
REMOTE MODE RS-485
BAUD RATE 9600
ID 255
USER
1. USER
To set up the user account for controlling. It
allows 8 users setting.
Supervisor – Control all the functions.
Other User – Review all functions except the
menu setting and event list
cleaning.
2. PASSWORD
To set the security password for each account.
The maximum length of user password is 4
characters.
(MENU)
TIMER
CAMERA
RECORD
ALARM
DWELL
PIP
MOTION
DISPLAY
REMOTE
USER
SYSTEM
EVENT
(USER)
PASSWORD
SUPERVISOR 0000
USER 1 0000
USER 2 0000
USER 3 0000
USER 4 0000
USER 5 0000
USER 6 0000
USER 7 0000
18
(DISPLAY)
TITLE DISPLAY YES
OSD COLOR YELLOW
BORDER TYPE 4/2
BORDER COLOR WHITE
LOSS SCREEN GREEN
OSD POSITION NORMAL
5. LOSS SCREEN
Retain the last picture or select the LOSS SCREEN color.
The options are GREEN, BLACK, BLUE.
6. OSD POSITION
To set the OSD POSITION shown on monitor.
The options are NORMAL or CENTER.
