MM-5100 Windows Setup Manual 090803 NZ Page 30 of 44 4/09/2003
9.1.2. Setting up WinFax ® General Properties
when using RS232 port.
1: You can define program and user setup by selecting this.
2: Setup Dialog Box
2-1: Option tab
2-2: Modem setup
3:
Modems and Comms Devices Properties Dialog Box
3-1: Leave it as “Default”
3-2: You must select Standard 19200bps Modem.
3-3: Select the Modem “Properties…” button
4:
Properties for MM-5100 General tab
4-1: Modem connects with COM 1
4-2: You must select “19200” bps
4-3: WinFax
® detects Class 2.0 automatically
NOTE: Under item 3-1 there may be 4 options as below:
1. Cellular (Analog/AMPS)
2. Cellular (PCS/GSM-Digital)
3. Default
4. Dial as entered
Any of these options can be selected and work well. But if possible select “default”.
